Lbz ecm/pcm/tcm Pinout with voltage rating?

G

Gideonr

New Member
Messages
1
Reaction score
0
I have an 06 Lbz 330k never skips a beat. Truck ran and drove great the other night. Now won’t rev past 1500rpm without stumbling/fuel knock. Lift pump is working, new filter head, filters, and fpr a couple months back. Truck is throwing u0100 and p0700. Looking for schematic for ecm/pcm/tcm connectors so I can hopefully narrow down what I believe to be a broken or shorting wire. Thanks in advance
